Rightway Brand TR-102A Ophthalmic Table and Chair unit
Specifications：
| TR-102A | ||
| Mechanical Parameters | Up/Down angle of swing arm | ±30° |
| Table size | 840mmx405mm, 670mmx405mm | |
| Table rotational angle | 90° | |
| Table sliding movement range | 330mm | |
| Angle of rotation for chair | ±60° | |
| Chair height adjustment range | 460~600mm | |
| Loading for chair | 150kgs | |
| Lifting height for pillow | ≤150mm | |
| Backrest obliquity | 90°~135° | |
| Electrical Parameters | Input voltage | 110V/220V AC 50Hz～60Hz |
| Engine power | 55W 220V AC | |
| Light | 16W 110V/220V AV | |
| Fuse | 5A 250V AC | |
| No load power | 1W | |
| Pressure test | 2KV | |
| Main wire | 10A 250V | |
| Working mode | S1 | |
| Working temperature | -10℃~ 40℃ | |
| Relative humility | less than 90% | |
| Installation Dimension | Figure size | 1560mm*1000mm*2000mm |
| Weight | 175kgs | |
Processing time
According your order list. we will supply delivery time .
Commonly is 5-7 work days after we confirm payment
Shipping time
By Express : 3-7 days . Door to door service
By Air : 3-7 days . (the goods arrival at your local air ports
By sea : 30-40 days (the goods arrival at your local sea ports )
PS : by air or by sea, if you need door to door service, please tell us . we will help you checking the extra door to door cost.
How many months warranty do you provide ?
one year
What should I do if the machine have question ?
For ensuring all the items are in good quality, we will test all products before the packages were sent out. Once the machine have some question, please don't worry. kindly send us some images of the situation , Video and machine series, and explain the question in where . we will supply solution to you deal soon.
What should I do if the spare parts is broken in Warranty ?
If in Warranty, some spare parts broken in the Use. kindly supply picture or video , and machine series number .
We will send the spare parts by express to you soon.. and we bear express cost .
