Specifications:
TR-700A | |||
Mechanical Parameters | 1.Phoroptor swing arm | Swing angle (up and down) | ±30° |
Rotary arm: rotation angle | 0°-300° | ||
Up and down moving range | 900mm~1500mm | ||
Max load | 30Kgs | ||
2.Auto keratometer arm | Swing angle (up and down) | ±40° | |
The first rotary arm rotates at an Angle | 360° | ||
The second rotary arm rotates at an Angle | 0°-300° | ||
The tray can be 360° rotation | |||
Up and down moving range | 780mm~1380mm | ||
Max load | 30Kgs | ||
3.Projector arm | Angle of rotation for rotary arm | 360° | |
The tray can be 360° rotation | |||
Up and down moving range | 1030mm~ 1530mm | ||
Max load | 10Kgs | ||
4.Slit lamp arm | Table size | 350mm x 200mm x25mm (Can be customized, maximum size is 700mmx 400mm x 40mm) | |
Max load | 50Kgs | ||
Table movement range | within a semicircle with a radius of 824mm | ||
Height adjustment range | 716mm ~1016mm | ||
Table rotational angle | The first rotary arm rotates at an Angle 0°- 180°; | ||
The second rotary arm rotates at an Angle 0°- 360°; | |||
The third rotary arm rotates at an Angle 0°- 180° | |||
Table-board rotational angle | 360° | ||
5.Seat parameter | Lifting range | 568~708mm | |
Headrest adjusting range | 250mm | ||
Seat rotation angle | 0°-270° | ||
Footrest height from ground | minimum 88mm | ||
Backrest adjusting angle | 80°-180° | ||
Max. load | 150Kgs | ||
Electrical Parameters | 1.In voltage | 100-120V AC 50Hz/60Hz, 200-240V AC 50Hz/60Hz | |
2.Output voltage | 100-120V AC 50Hz/60Hz, 200-240V AC 50Hz/60Hz; | ||
2.5V 3.5V 4.5V 5.5V 6.5V 7.5V 12V AC | |||
3.Charging voltage | 5V DC | ||
4.Engine power | 28V 1.5A DC | ||
5.Light | 5/16W 24V DC | ||
6.Fuse | 5A 130/250V AC | ||
7.No load power | 1W | ||
8.Pressure test | 2KV | ||
9.Working mode | S1 | ||
10.Main wire | 10A 120V/250V | ||
11.Working temperature | -10℃~ 40℃ | ||
12.Relative humidity | less than 90% | ||
Installation Dimension | Figure size | 1884mm*1316mm*1663mm(No contain table top or lighting) | |
Weight | 295kgs |
Ophthalmic unit
Features:
With visua black-box, suitable for all open enviroment, clean and polished contour, meeting the requirments for the upgrade refraction environment.
1. European style elegant design;
2. Rotating mobile sliding table for refractometer;
3. Operation interface and high-class halogen lamp adopting one-click with multi-purpose design,;
4. simplifying the operation and improving the comfort level
Processing time
According your order list. we will supply delivery time .
Commonly is 5-7 work days after we confirm payment
Shipping time
By Express : 3-7 days . Door to door service
By Air : 3-7 days . (the goods arrival at your local air ports
By sea : 30-40 days (the goods arrival at your local sea ports )
PS : by air or by sea, if you need door to door service, please tell us . we will help you checking the extra door to door cost.
How many months warranty do you provide ?
one year
What should I do if the machine have question ?
For ensuring all the items are in good quality, we will test all products before the packages were sent out. Once the machine have some question, please don't worry. kindly send us some images of the situation , Video and machine series, and explain the question in where . we will supply solution to you deal soon.
What should I do if the spare parts is broken in Warranty ?
If in Warranty, some spare parts broken in the Use. kindly supply picture or video , and machine series number .
We will send the spare parts by express to you soon.. and we bear express cost .
