YZ23B Ophthalmic Synoptophore
Features:
Ø Diagnosis and treatment combined with the functions of simultaneous perception, fusion, stereopsis, red reflex and after-image.
Ø Equipped with a pair of Haidingers Brush and 20 pairs of pictures with different functions.
Ø Using transflective reflector in the design of viewing system to facilitate the user to observe ocular position.
Ø Using advanced LED light in the illumination with even illumination, low heat and long service life.
Ø Pictures designed by new technology are anti-broken and has long service life.
Ø Manual or automatic coruscation with accurate frequency and various type is at user's option.
Ø Optional pictures are provided for quantitative measuring of stereopsis acuity (40”~1000”)
Parameters:
Magnification | 1.65× |
Diameter of Field | ≥56mm |
Red Light | λ = 640nm coruscation system |
Pictures of left and right can be moved up and down according optical axis | ±10Δ |
Pictures of left and right rotate around optical axis | ±20° |
Pupilary Adjustment | 45~75mm |
Darkroom Illumination | LED bulb with symmetry design |
Adjustable Haidingers Brush | 50~100 round/minute |
Coruscation Form | manual or automatic |
Automatic Coruscation Frequency | 10-Steps, 30~300 times/minute |
Range of Automatic Coruscation ( each cycle) | 1/4 on 3/4 off, 1/2 on 1/2 off, 3/4 on 1/4 off |
Type of Automatic Coruscation | Left and right can be turned on or off at the same time Left and right can be turned on or off alternatively One on and the other off One on or off while the other can be turned on or off |
Processing time
According your order list. we will supply delivery time .
Commonly is 5-7 work days after we confirm payment
Shipping time
By Express : 3-7 days . Door to door service
By Air : 3-7 days . (the goods arrival at your local air ports
By sea : 30-40 days (the goods arrival at your local sea ports )
PS : by air or by sea, if you need door to door service, please tell us . we will help you checking the extra door to door cost.
How many months warranty do you provide ?
one year
What should I do if the machine have question ?
For ensuring all the items are in good quality, we will test all products before the packages were sent out. Once the machine have some question, please don't worry. kindly send us some images of the situation , Video and machine series, and explain the question in where . we will supply solution to you deal soon.
What should I do if the spare parts is broken in Warranty ?
If in Warranty, some spare parts broken in the Use. kindly supply picture or video , and machine series number .
We will send the spare parts by express to you soon.. and we bear express cost .
