Optical System BY-5
Type: Galilean system
Magnification Changer: Rotating drum change
Magnification:5 steps by drum rotation
Field of view: 16x(φ33)mm 10x(φ22.5) 16x(φ14)mm
Pupil Range: 52 - 82 mm
Diopter: ±7D
llumination
Slit Width: Continuous from 0 to 14 mm
Slit Length: Continuous from 1 to 14 mm
Slit angle: 0° - 180°
Slit Aperture: Continuous from 1 - 10 mm, φ14,10, 5, 3, 2, 1, 0.2 mm
Filter: Heat Absorption, Grey, Redfree, Cobalt Blue
Power
Input Voltage: 110-220V 50-60Hz
Input Power: 68VA
Dimensions and Weight
Dimensions: 700*460*440 mm
Net Weight: 16kg
Gross Weight: 18kg
thank you so much for liking that By 新一帆光学
Processing time
According your order list. we will supply delivery time .
Commonly is 5-7 work days after we confirm payment
Shipping time
By Express : 3-7 days . Door to door service
By Air : 3-7 days . (the goods arrival at your local air ports
By sea : 30-40 days (the goods arrival at your local sea ports )
PS : by air or by sea, if you need door to door service, please tell us . we will help you checking the extra door to door cost.
How many months warranty do you provide ?
one year
What should I do if the machine have question ?
For ensuring all the items are in good quality, we will test all products before the packages were sent out. Once the machine have some question, please don't worry. kindly send us some images of the situation , Video and machine series, and explain the question in where . we will supply solution to you deal soon.
What should I do if the spare parts is broken in Warranty ?
If in Warranty, some spare parts broken in the Use. kindly supply picture or video , and machine series number .
We will send the spare parts by express to you soon.. and we bear express cost .
