Digital Slit Lamp Microscope BL-88D
Feature
Professional acquisition media
The machine uses SLR camera as acquisition media, real-time dynamic display, the image is clear lifelike and it's very quick to image acquisition .
Take pictures quickly
With outer shooting device, just run through the lesion site and press the device, clear images captured immediately.
Powerful image processing functions
Can be used to measure the length, area, Angle, gray, curvature, etc, and also can mark lesions, add text on the pictures
High-definition image
The instrument can take as much as 18 million pixels photos, and provide the highest of 40 times magnification to show the details in micros ,
meeting the stringent requirements of medical image, will show lesions more clearly.
Have the auxiliary function for diagnosis
Offers a variety of common eye disease diagnosis model of parameters Settings, improve the efficiency of the diagnosis.
Have medical records management and output
Medical report can be stored, management, and printed
Accessories :
1.Camera adaptor
2.camera splitter
3.Professional digital single lens reflexs camera
4.Bolan slit lamp processing microsoft system
5.Apple PC computer(for option)
6. High-definition ink-jet printer(for option)
Microscope | Microscope Type | Galilean stereoscopic microscope |
| Magnification Selection | 5 steps by drum rotation |
| Eyepiece | 12.5x |
| Magnification Ratio (Field of view ) | 6×(φ33mm),10×(φ22.5),16×(φ14mm),25×(φ8.8mm),40×(φ5.5mm) |
| Pupillary Adjustment | 50mm ~ 82mm |
| Diopter Adjustment | +7D ~ -7D |
Base | Side Shift | 110mm |
| Depth Shift | 90mm |
Chin rest | Height Shift | 30mm |
| Height Shift | 80mm |
| Fixation Target | Red LED |
Illumination System | Slit width | 0 ~ 14mm continuous (at 14mm,slit becomes a circle) |
| Slit height | 1 ~ 14mm continuous |
| Slit angle | 0 ~ 1800 continuous |
| Slit Inclination | 0 0,50,150,200 |
| Diameter of Light Spot | 14mm ,10mm,5mm ,3mm,2mm,1mm,0.2mm,1mm, 1-14mm continuous |
| Filter | Heat absorption ,Grey ,Red-Free ,Cobalt Blue |
| Illumination bulb | 12V 50W halogen lamp |
Power | Input voltage | 110V/220V |
| Frequency | 50/60HZ |
| Power consuption | 68VA |
Weight and size | Gross Weight | 18kg |
| Dimension | 690mm(L)× 440mm(W)× 420mm(H) |
Processing time
According your order list. we will supply delivery time .
Commonly is 5-7 work days after we confirm payment
Shipping time
By Express : 3-7 days . Door to door service
By Air : 3-7 days . (the goods arrival at your local air ports
By sea : 30-40 days (the goods arrival at your local sea ports )
PS : by air or by sea, if you need door to door service, please tell us . we will help you checking the extra door to door cost.
How many months warranty do you provide ?
one year
What should I do if the machine have question ?
For ensuring all the items are in good quality, we will test all products before the packages were sent out. Once the machine have some question, please don't worry. kindly send us some images of the situation , Video and machine series, and explain the question in where . we will supply solution to you deal soon.
What should I do if the spare parts is broken in Warranty ?
If in Warranty, some spare parts broken in the Use. kindly supply picture or video , and machine series number .
We will send the spare parts by express to you soon.. and we bear express cost .
